Grafana + Prometheus Homelab Monitoring: Full Stack Setup in 30 Minutes

Flying blind is fine — until something breaks at 2am and you have no idea what happened, when it started, or which machine is responsible.

A proper monitoring stack gives you three things: visibility into what your systems are doing right now, history so you can see trends and spot problems before they bite, and alerts that tell you when something needs attention — before your users do.

This guide builds a complete monitoring stack for your homelab using industry-standard tools:

• Prometheus — collects and stores metrics from all your machines
• Grafana — turns those metrics into dashboards you can actually read
• Node Exporter — exposes Linux system metrics (CPU, RAM, disk, network)
• cAdvisor — exposes Docker container metrics
• Alertmanager — sends alerts to email, Telegram, or Slack when things go wrong

Everything runs in Docker Compose. One file, one command, full observability.

---

How It All Fits Together

Before diving into config files, here’s the data flow:

Your machines
  └── Node Exporter  →  exposes metrics at :9100
  └── cAdvisor       →  exposes container metrics at :8080

Prometheus
  └── scrapes Node Exporter every 15s
  └── scrapes cAdvisor every 15s
  └── stores metrics on disk
  └── evaluates alert rules
  └── fires alerts to Alertmanager

Alertmanager
  └── routes alerts to Telegram / email / Slack

Grafana
  └── queries Prometheus for data
  └── renders dashboards in your browser

Prometheus is the brain — it pulls data from everything and stores it. Grafana is the eyes — it reads from Prometheus and shows you what’s happening.

---

What You Need

• Ubuntu 22.04+ or Debian 12+ on the monitoring host
• Docker and Docker Compose installed (see the Docker setup guide or install with curl -fsSL https://get.docker.com | sh)
• 2 GB RAM free on the monitoring host (Grafana + Prometheus are not heavy)
• Port access to your other machines for scraping

---

Step 1 — Create the Project Structure

mkdir -p ~/monitoring/{prometheus,grafana/provisioning/{datasources,dashboards},alertmanager}
cd ~/monitoring

Your structure:

monitoring/
├── docker-compose.yml
├── prometheus/
│   ├── prometheus.yml          ← what to scrape and how often
│   └── alerts.yml              ← alert rules
├── alertmanager/
│   └── alertmanager.yml        ← where to send alerts
└── grafana/
    └── provisioning/
        ├── datasources/
        │   └── prometheus.yml  ← auto-connect Grafana to Prometheus
        └── dashboards/
            └── dashboards.yml  ← auto-load dashboards on startup

---

Step 2 — Prometheus Configuration

Prometheus needs to know what to scrape. Create the main config:

# prometheus/prometheus.yml
global:
  scrape_interval:     15s   # pull metrics every 15 seconds
  evaluation_interval: 15s   # evaluate alert rules every 15 seconds
  scrape_timeout:      10s

# Alert rules file
rule_files:
  - "alerts.yml"

# Send alerts to Alertmanager
alerting:
  alertmanagers:
    - static_configs:
        - targets: ['alertmanager:9093']

# What to scrape
scrape_configs:

  # Prometheus itself
  - job_name: 'prometheus'
    static_configs:
      - targets: ['localhost:9090']

  # Linux host metrics (from Node Exporter)
  - job_name: 'node-exporter'
    static_configs:
      - targets:
          - 'node-exporter:9100'      # local machine
          - '192.168.1.10:9100'       # node-01
          - '192.168.1.11:9100'       # node-02
          # add more machines here

  # Docker container metrics
  - job_name: 'cadvisor'
    static_configs:
      - targets: ['cadvisor:8080']

  # Ollama metrics (if you followed the Ollama guide)
  - job_name: 'ollama'
    static_configs:
      - targets: ['192.168.1.x:11434']
    metrics_path: /metrics

Replace the IP addresses with your actual machine IPs. Add or remove targets as needed — Prometheus will scrape whatever you list here.

---

Step 3 — Alert Rules

Alerts are evaluated by Prometheus against the stored metrics. When a rule fires, Prometheus sends the alert to Alertmanager.

# prometheus/alerts.yml
groups:
  - name: homelab.rules
    rules:

      # Host is unreachable
      - alert: HostDown
        expr: up == 0
        for: 2m
        labels:
          severity: critical
        annotations:
          summary: "Host {{ $labels.instance }} is down"
          description: "{{ $labels.instance }} has been unreachable for more than 2 minutes."

      # CPU over 85% for 5 minutes
      - alert: HighCPULoad
        expr: 100 - (avg by(instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 85
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High CPU load on {{ $labels.instance }}"
          description: "CPU load is {{ printf \"%.1f\" $value }}% on {{ $labels.instance }}"

      # RAM over 90% used
      - alert: HighMemoryUsage
        expr: (1 - (node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes)) * 100 > 90
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High memory usage on {{ $labels.instance }}"
          description: "Memory usage is {{ printf \"%.1f\" $value }}% on {{ $labels.instance }}"

      # Disk over 85% full
      - alert: DiskSpaceLow
        expr: (1 - (node_filesystem_avail_bytes{fstype!~"tmpfs|fuse.lxcfs|squashfs"} / node_filesystem_size_bytes)) * 100 > 85
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "Low disk space on {{ $labels.instance }}"
          description: "Disk {{ $labels.mountpoint }} is {{ printf \"%.1f\" $value }}% full on {{ $labels.instance }}"

      # Disk over 95% full — critical
      - alert: DiskSpaceCritical
        expr: (1 - (node_filesystem_avail_bytes{fstype!~"tmpfs|fuse.lxcfs|squashfs"} / node_filesystem_size_bytes)) * 100 > 95
        for: 2m
        labels:
          severity: critical
        annotations:
          summary: "CRITICAL disk space on {{ $labels.instance }}"
          description: "Disk {{ $labels.mountpoint }} is {{ printf \"%.1f\" $value }}% full. Immediate action required."

      # Docker container restarting repeatedly
      - alert: ContainerRestarting
        expr: rate(container_last_seen{name!=""}[5m]) > 0 and delta(container_restart_count[5m]) > 2
        for: 2m
        labels:
          severity: warning
        annotations:
          summary: "Container {{ $labels.name }} is restarting"
          description: "Container {{ $labels.name }} has restarted more than twice in the last 5 minutes."

These rules cover the most common homelab failure modes. You can add more later — Prometheus’s query language (PromQL) is powerful once you get used to it.

---

Step 4 — Alertmanager Configuration

Alertmanager receives firing alerts from Prometheus and routes them to you. Here’s a config that supports Telegram (free, instant, works great for homelabs):

# alertmanager/alertmanager.yml
global:
  resolve_timeout: 5m

route:
  group_by: ['alertname', 'instance']
  group_wait:      30s
  group_interval:  5m
  repeat_interval: 12h
  receiver: 'telegram'

  # Route critical alerts immediately, no grouping wait
  routes:
    - match:
        severity: critical
      receiver: 'telegram'
      group_wait: 10s
      repeat_interval: 1h

receivers:
  - name: 'telegram'
    telegram_configs:
      - api_url: 'https://api.telegram.org'
        bot_token: 'YOUR_BOT_TOKEN'       # ← from BotFather
        chat_id: YOUR_CHAT_ID             # ← your Telegram chat ID
        message: |
          {{ range .Alerts }}
          *{{ .Status | toUpper }}* {{ .Labels.alertname }}
          Instance: {{ .Labels.instance }}
          {{ .Annotations.summary }}
          {{ .Annotations.description }}
          {{ end }}
        parse_mode: 'Markdown'

  # Email alternative (uncomment to use instead of or alongside Telegram)
  # - name: 'email'
  #   email_configs:
  #     - to: 'you@yourdomain.com'
  #       from: 'alertmanager@yourdomain.com'
  #       smarthost: 'smtp.gmail.com:587'
  #       auth_username: 'you@gmail.com'
  #       auth_password: 'your-app-password'

inhibit_rules:
  # If a host is down, suppress all other alerts from that host
  - source_match:
      alertname: 'HostDown'
    target_match_re:
      alertname: '.+'
    equal: ['instance']

Setting up Telegram alerts (takes 3 minutes):

1. Open Telegram → search for @BotFather → send /newbot
2. Follow the prompts → BotFather gives you a token — paste it into bot_token
3. Send any message to your new bot, then visit: https://api.telegram.org/bot<YOUR_TOKEN>/getUpdates
4. Find "chat":{"id": in the response — that number is your chat_id

---

Step 5 — Grafana Auto-Provisioning

Grafana can automatically connect to Prometheus and load dashboards on startup — no manual clicking required.

# grafana/provisioning/datasources/prometheus.yml
apiVersion: 1

datasources:
  - name: Prometheus
    type: prometheus
    access: proxy
    url: http://prometheus:9090
    isDefault: true
    editable: false

# grafana/provisioning/dashboards/dashboards.yml
apiVersion: 1

providers:
  - name: 'homelab'
    orgId: 1
    folder: 'Homelab'
    type: file
    disableDeletion: false
    updateIntervalSeconds: 30
    options:
      path: /var/lib/grafana/dashboards

This tells Grafana: “Prometheus is your data source, and load any JSON dashboards from that path.” You can drop dashboard JSON files in there and they appear automatically — no import needed.

---

Step 6 — The Docker Compose File

This is the file that runs everything. One command starts the entire stack.

# docker-compose.yml
services:

  # ── Prometheus ────────────────────────────────────────────────
  prometheus:
    image: prom/prometheus:latest
    container_name: prometheus
    restart: unless-stopped
    ports:
      - "9090:9090"
    volumes:
      - ./prometheus/prometheus.yml:/etc/prometheus/prometheus.yml:ro
      - ./prometheus/alerts.yml:/etc/prometheus/alerts.yml:ro
      - prometheus-data:/prometheus
    command:
      - '--config.file=/etc/prometheus/prometheus.yml'
      - '--storage.tsdb.path=/prometheus'
      - '--storage.tsdb.retention.time=90d'     # keep 90 days of data
      - '--web.console.libraries=/usr/share/prometheus/console_libraries'
      - '--web.console.templates=/usr/share/prometheus/consoles'
      - '--web.enable-lifecycle'                # allow config reload via API

  # ── Grafana ───────────────────────────────────────────────────
  grafana:
    image: grafana/grafana:latest
    container_name: grafana
    restart: unless-stopped
    ports:
      - "3001:3000"            # 3001 to avoid clash with Open WebUI on 3000
    volumes:
      - grafana-data:/var/lib/grafana
      - ./grafana/provisioning:/etc/grafana/provisioning:ro
    environment:
      - GF_SECURITY_ADMIN_USER=admin
      - GF_SECURITY_ADMIN_PASSWORD=changeme     # ← change this
      - GF_USERS_ALLOW_SIGN_UP=false
      - GF_SERVER_DOMAIN=localhost
      - GF_ANALYTICS_REPORTING_ENABLED=false    # disable telemetry
      - GF_ANALYTICS_CHECK_FOR_UPDATES=false
    depends_on:
      - prometheus

  # ── Node Exporter ─────────────────────────────────────────────
  node-exporter:
    image: prom/node-exporter:latest
    container_name: node-exporter
    restart: unless-stopped
    network_mode: host        # needs host networking to see real system metrics
    pid: host
    volumes:
      - /proc:/host/proc:ro
      - /sys:/host/sys:ro
      - /:/rootfs:ro
    command:
      - '--path.procfs=/host/proc'
      - '--path.sysfs=/host/sys'
      - '--path.rootfs=/rootfs'
      - '--collector.filesystem.mount-points-exclude=^/(sys|proc|dev|host|etc)($$|/)'

  # ── cAdvisor ──────────────────────────────────────────────────
  cadvisor:
    image: gcr.io/cadvisor/cadvisor:latest
    container_name: cadvisor
    restart: unless-stopped
    ports:
      - "8080:8080"
    volumes:
      - /:/rootfs:ro
      - /var/run:/var/run:ro
      - /sys:/sys:ro
      - /var/lib/docker/:/var/lib/docker:ro
      - /dev/disk/:/dev/disk:ro
    privileged: true
    devices:
      - /dev/kmsg

  # ── Alertmanager ──────────────────────────────────────────────
  alertmanager:
    image: prom/alertmanager:latest
    container_name: alertmanager
    restart: unless-stopped
    ports:
      - "9093:9093"
    volumes:
      - ./alertmanager/alertmanager.yml:/etc/alertmanager/alertmanager.yml:ro
      - alertmanager-data:/alertmanager
    command:
      - '--config.file=/etc/alertmanager/alertmanager.yml'
      - '--storage.path=/alertmanager'

volumes:
  prometheus-data:
  grafana-data:
  alertmanager-data:

---

Step 7 — Start the Stack

cd ~/monitoring

# Start everything in the background
docker compose up -d

# Watch the logs to make sure everything came up cleanly
docker compose logs -f

After 20–30 seconds, open these URLs in your browser:

Service	URL	Default login
Grafana	http://localhost:3001	admin / changeme
Prometheus	http://localhost:9090	— (no login)
Alertmanager	http://localhost:9093	— (no login)
Node Exporter	http://localhost:9100/metrics	—
cAdvisor	http://localhost:8080	—

Change the Grafana password immediately — click your avatar bottom-left → Profile → Change password.

---

Step 8 — Import Dashboards

Grafana has a community dashboard library with thousands of pre-built dashboards. You don’t need to build anything from scratch.

Import the Node Exporter Full dashboard:

1. In Grafana → left sidebar → Dashboards → Import
2. Enter dashboard ID: 1860 → click Load
3. Select Prometheus as the data source → Import

You now have a full system dashboard: CPU, RAM, disk I/O, network, load average, and more — for every machine running Node Exporter.

Other dashboard IDs worth importing:

ID	Dashboard	What it shows
1860	Node Exporter Full	Complete Linux system metrics
893	Docker and system monitoring	Container CPU, memory, network
15798	Grafana internals	Grafana’s own performance
3662	Prometheus 2.0 stats	Prometheus scrape performance
11074	Node Exporter for Prometheus	Clean minimal system view

---

Step 9 — Install Node Exporter on Other Machines

Prometheus can only scrape a machine if Node Exporter is running on it. You need to install Node Exporter on every machine you want to monitor.

Quick install script (run on each target machine):

# Download Node Exporter
wget https://github.com/prometheus/node_exporter/releases/download/v1.8.2/node_exporter-1.8.2.linux-amd64.tar.gz

# Extract
tar xvf node_exporter-1.8.2.linux-amd64.tar.gz
sudo mv node_exporter-1.8.2.linux-amd64/node_exporter /usr/local/bin/

# Create a systemd service
sudo tee /etc/systemd/system/node_exporter.service << 'EOF'
[Unit]
Description=Node Exporter
After=network.target

[Service]
User=nobody
ExecStart=/usr/local/bin/node_exporter
Restart=always

[Install]
WantedBy=multi-user.target
EOF

# Start it
sudo systemctl daemon-reload
sudo systemctl enable --now node_exporter

# Verify
curl http://localhost:9100/metrics | head -20

If you followed the Ansible guide, you can add a Node Exporter role and deploy this to every machine in one command. That’s the better long-term approach.

---

Step 10 — Open Firewall Ports

Prometheus needs to reach port 9100 on each machine it scrapes. On each target machine:

# Allow Prometheus to scrape Node Exporter from your LAN
sudo ufw allow from 192.168.1.0/24 to any port 9100

# Reload UFW
sudo ufw reload

Replace 192.168.1.0/24 with your actual LAN subnet.

On the monitoring host, open the Grafana port if you want to reach it from other devices:

sudo ufw allow from 192.168.1.0/24 to any port 3001

---

Useful PromQL Queries

PromQL is Prometheus’s query language. You use it in Grafana to build panels. Here are the most useful ones for a homelab:

# CPU usage per machine (%)
100 - (avg by(instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

# RAM used (%)
(1 - (node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes)) * 100

# Disk usage per mount point (%)
(1 - (node_filesystem_avail_bytes / node_filesystem_size_bytes)) * 100

# Network traffic in (bytes/sec)
rate(node_network_receive_bytes_total{device!~"lo|veth.*"}[5m])

# Network traffic out (bytes/sec)
rate(node_network_transmit_bytes_total{device!~"lo|veth.*"}[5m])

# System load average (1 minute)
node_load1

# Uptime in days
(node_time_seconds - node_boot_time_seconds) / 86400

# Number of running Docker containers
count(container_last_seen{name!=""})

# Container CPU usage (%)
rate(container_cpu_usage_seconds_total{name!=""}[5m]) * 100

# Container memory usage (bytes)
container_memory_usage_bytes{name!=""}

Paste these into the Grafana panel editor to build custom dashboards tuned exactly to your setup.

---

Reloading Config Without Restarting

Prometheus supports live config reload — you can add new scrape targets without downtime.

# After editing prometheus.yml, reload without restart
curl -X POST http://localhost:9090/-/reload

For Alertmanager:

curl -X POST http://localhost:9093/-/reload

Grafana picks up provisioning changes automatically every 30 seconds (configured in dashboards.yml).

---

Day-to-Day Commands

# Check all containers are running
docker compose ps

# View logs for one service
docker compose logs -f grafana
docker compose logs -f prometheus

# Restart one service after config change
docker compose restart prometheus

# Stop the whole stack (data is preserved in volumes)
docker compose down

# Stop and delete all data (careful)
docker compose down -v

# Check disk usage of Prometheus data
docker volume inspect monitoring_prometheus-data
du -sh /var/lib/docker/volumes/monitoring_prometheus-data/

---

Troubleshooting

Prometheus shows targets as DOWN:

Go to Prometheus → Status → Targets. Each target shows its last scrape status and error message. Common causes:

• Node Exporter not running on the target machine
• Firewall blocking port 9100 between Prometheus and target
• Wrong IP in prometheus.yml

Test reachability from the monitoring host:

curl http://192.168.1.10:9100/metrics | head -5

If that returns metrics — Prometheus can scrape it. If it times out — it’s a firewall issue.

Grafana shows “No data”:

• Check Prometheus is actually scraping data: go to http://localhost:9090 and run a query like up
• Check the time range in Grafana — default is “last 6 hours”, there might be no data yet if you just started
• Check the datasource: Grafana → Connections → Data sources → Prometheus → click Test — should say “Data source is working”

Alertmanager not sending Telegram alerts:

Test manually by sending a fake alert:

curl -H 'Content-Type: application/json' -d '[{
  "labels": {"alertname": "TestAlert", "instance": "test"},
  "annotations": {"summary": "This is a test"}
}]' http://localhost:9093/api/v1/alerts

Check the Alertmanager logs:

docker compose logs alertmanager

If you see the alert was received but Telegram shows nothing — double-check your bot_token and chat_id.

---

What’s Next

Your homelab is now fully observable. You can see CPU, RAM, disk, network, and container health across every machine — in real time and historically.

The natural next steps from here:

• Automate the install with Ansible — the Ansible guide shows you how to deploy Node Exporter to every machine with one command
• Add Loki for log aggregation — Prometheus handles metrics, Loki handles logs. Together they give you the full Grafana observability stack
• Set up Uptime Kuma — a simple, beautiful status page that monitors your services and sends alerts when they go down. Pairs perfectly with this stack for external endpoint monitoring
• Connect Ollama metrics — if you followed the Ollama guide, Prometheus can scrape model inference stats — requests per second, token generation speed, queue depth

When your lab breaks — and it will — you’ll know exactly what happened, when it happened, and which machine to look at first. That’s what monitoring gives you.
